Installation

WIPER / WASHER: RELAY (w/ Headlight Cleaner System): INSTALLATION


1. INSTALL HEADLIGHT CLEANER CONTROL RELAY






(a) Install the headlight cleaner control relay in the direction shown in the illustration.
(b) Connect the connector.
2. INSTALL WINDSHIELD WASHER JAR ASSEMBLY Installation

3. INSTALL WASHER INLET SUB-ASSEMBLY Installation

4. FILL WINDSHIELD WASHER JAR AND PUMP ASSEMBLY WITH WASHER FLUID Installation

5. INSTALL FRONT FENDER LINER LH Installation

6. INSTALL SIDE STEP ASSEMBLY Installation

7. INSTALL HEIGHT CONTROL PROTECTOR PIPE Installation

8. INSTALL FRONT FENDER MUDGUARD LH Installation

9. INSTALL ENGINE ROOM SIDE COVER LH Installation
