Rear Heating and A/C Unit, Assembly

Rear Heating And A/C Unit, Assembly







1 - Rear heater core
2 - Foam gasket
3 - Right air volume flap
4 - Coolant hose
- Supply to rear heater core.
5 - Coolant hose
- Return from rear heater core.
6 - Right Rear Temperature Flap Motor -V314-
7 - Rear Blower Regulation Sensor -G463-
8 - O-ring
- Always replace
- 14.3 mm; 2.4 mm
9 - O-ring
- Always replace
- 10.8 mm; 1.8 mm
10 - O-ring
- Always replace
- 14.3 mm; 2.4 mm
11 - O-ring
- Always replace
- 10.8 mm; 1.8 mm
12 - Evaporator water drain valve/hose
- Upon installation, ensure hose is not kinked.
13 - Bolt
14 - Expansion valve
15 - O-ring
- Always replace
- 10.8 mm; 1.8 mm
16 - O-ring
- Always replace
- 14.3 mm; 2.4 mm
17 - Rear evaporator
18 - Cover
- Where applicable
19 - Left Rear Temperature Flap Motor -V313-
20 - Rear Blower Regulation Motor (Bitron) -V306-
21 - Left air volume flap
22 - Left Rear Air Flap Motor -V239-
23 - Right Rear Air Flap Motor -V240-
24 - Left Rear Vent Temperature Sensor -G405-
- Removing.
25 - Right Rear Vent Temperature Sensor -G406-
- Removing.
26 - Foam gasket
