Cabin Air Filter / Purifier: Locations

The filter is located in the right rear of the instrument panel under a cover.









Components of dust and pollen filter.
1 - Frame
3 - Filter element
4 - Plastic nut, 2.5 Nm (20 in lb)
5 - Filter housing with seal
