Installation

METER: LIGHT CONTROL RHEOSTAT (for Hatchback): INSTALLATION

1. INSTALL LIGHT CONTROL RHEOSTAT





(a) Engage the 2 claws and install the light control rheostat.

(b) Connect the connector.

2. INSTALL INSTRUMENT PANEL BOX Installation

3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Torque : 5.4 Nm (55 kgf-cm, 48 in-lbf)
