SMT Warning Light Circuit

CIRCUIT DESCRIPTION

SMT warning light inside the combination meter informs the driver of an auto-clutch system error and mis-operation (for example, start in 3rd gear is attempted) by flashing or lighting up respectively. Shorting TC and CG of the DLC3 makes SMT warning light flash and output DTCs.
