Interior Moulding / Trim: Locations

Instrument Panel (Part 1):

Instrument Panel (Part 2):

Instrument Panel (Part 3):

Roof Headlining:

HINT: Screw shapes and size are indicated in the table. The code ("A"-"P") correspond to those indicated.
