Crankshaft Position Sensor: Service and Repair

CRANKSHAFT POSITION SENSOR REMOVAL





1. DISCONNECT CRANKSHAFT POSITION SENSOR CONNECTOR
2. REMOVE CRANKSHAFT POSITION SENSOR
- Remove the bolt and crankshaft position sensor.

Torque: 9.3 N.m (95 Kgf.cm, 82 in.lbf)

CRANKSHAFT POSITION SENSOR INSTALLATION

INSTALLATION HINT: Installation is in the reverse order of removal.
