Door Sensor/Switch (For Alarm): Testing and Inspection

Door Courtesy Switch Testing:

1. Check that there is continuity between terminal and ground when switch is released.
2. Check that there is no continuity between terminal and ground when switch is depressed.
3. If not as specified, replace switch.
