Cruise Main Indicator Light Circuit

CRUISE MAIN INDICATOR LIGHT CIRCUIT

CIRCUIT DESCRIPTION
- The ECM detects a cruise control switch signal and sends it to the combination meter via BEAN. Then the CRUISE main indicator light comes on.
- The CRUISE main indicator light circuit uses BEAN for communication. If there are any malfunctions in this circuit, check for DTCs in the multiplex communication system.
