Heater Core: Service and Repair

REMOVAL

1. REMOVE HEATER UNIT




2. REMOVE HEATER RADIATOR
a. Remove 3 screws and 3 plates and clamp.
b. Pull the radiator upward.

INSTALLATION
Installation is in the reverse order of removal.
