Air Bag Control Module: Testing and Inspection

INSPECTION
1. VEHICLES NOT INVOLVED IN A COLLISION
Do a diagnostic System check.

2. VEHICLES INVOLVED IN A COLLISION AND SRS IS NOT DEPLOYED
Do a diagnostic system check.

3. VEHICLES INVOLVED IN A COLLISION AND SRS IS DEPLOYED
Replace the airbag sensor assembly.

REPLACEMENT REQUIREMENT
In the following cases, replace the airbag sensor assembly.
^ If the SRS has been deployed in a collision.
^ If the airbag sensor assembly has been found to be faulty in troubleshooting.
^ If the airbag sensor assembly has been dropped.
