Removal and Installation

REMOVAL
1. REMOVE COOLING UNIT
2. REMOVE INSTRUMENT PANEL AND REINFORCEMENT
3. REMOVE PILLAR BRACE
Remove the 2 nuts, bolt and brace.




4. REMOVE BLOWER UNIT
a. Disconnect the connector.
b. Remove the 3 nuts and blower unit.

INSTALLATION
Installation is in the reverse order of removal.
