Instrument Panel and Center Console

Position Of Parts In Instrument Panel (Part 1 Of 2) (Fig 32):

Position Of Parts In Instrument Panel (Part 2 Of 2) (Fig 33):

A12 A/C Amplifier
A13 A/C Control SW
A14 A/C Thermistor
A15 ABS Deceleration Sensor
A16 ABS ECU
A17 ABS ECU
A15 Airbag Sensor Assembly
A19 Airbag Squib (Front Passenger Airbag Assembly)
A20 Airbag Squib (Steering Wheel Pad)

B 3 Blower Motor
B 4 Blower Resistor
B 5 Blower SW
B 6 Buckle SW LH

C 4 Center Diff. Lock Control SW
C 5 Cigarette Lighter
C 6 Cigarette Lighter Illumination
C 7 Clock
C 8 Clutch Start SW
C 9 Combination Meter
C10 Combination Meter
C11 Combination Meter
C12 Combination SW
C13 Combination SW
C14 Combination SW
C15 Cruise Control Clutch SW
C16 Cruise Control ECU

D 2 Data Link Connector 3
D 3 Defroster Mode SW
D 4 Diode (Engine Idle-Up)
D 5 Door Lock Control Relay
D17 Daytime Running Light Relay (Main)
D18 Diode No.1 (Daytime Running Light System)
D19 Diode No.2 (Daytime Running Light System)

E 3 Electronically Controlled Transmission Pattern Select SW
E 4 Engine Control Module
E 5 Engine Control Module
E 6 Engine Control Module

F 8 Fuse Block

H 4 Hazard SW

I10 Ignition SW

J 1 Junction Connector
J 2 Junction Connector
J 3 Junction Connector
J 4 Junction Connector
J 6 Junction Connector
J 7 Junction Connector

K 2 Key Interlock Solenoid

O 4 O/D Main SW

P 2 Parking Brake SW

R 3 Radio and Player
R 4 Radio and Player
R 5 Rear Window Defogger SW
R 6 Remote Control Mirror SW
R 7 Rheostat

S 4 Shift Lock ECU
S 5 Stop Light SW

U 1 Unlock Warning SW
