Rear Pads

Fig. 6 Adjusting Rear Caliper Piston:

1. Raise and support vehicle, then remove wheels.
2. Remove caliper pin bolts, then release parking brake lever.
3. Remove caliper from caliper carrier. Hang removed caliper with wire hook to prevent damage to brake hose.
4. Remove pads.
5. Reverse procedure to install, noting the following:
a. Using tool shown in Fig. 6, Turn caliper piston clockwise to obtain clearance between disc and pad.
b. Torque caliper pin bolts to specifications.
c. Once job has been completed, depress brake pedal five times to obtain proper disc to pad clearance.
