Fans In Rear Doors, Changing

To Remove
1 Remove the rear door trim.
2 Fold the sound insulation out of the way.
3 Remove the air intake grille and the air outlet grille.
4 Remove the rear door fan.

Installation
5 Install the rear door fan in the side of the door
6 Install the air intake grille and the air outlet grille.
7 Fold back the sound insulation.
8 Plug in the connector and install the rear door trim on the inside of the door.
9 90-Calibrate the Automatic Climate Control (ACC) system by pressing the "AUTO" and "VENT" buttons at the same time.

Important : During calibration, all previously stored diagnostic trouble codes are erased. Before carrying out calibration, all stored diagnostic trouble codes should be read.
