Fuel Pressure Regulator: Service and Repair

Fig. 7 Replacing pressure regulator:

1. Remove three retaining screws (3) that secure pressure regulator (2) to throttle body (1), Fig. 7.
2. Remove pressure regulator assembly, noting location of components.
3. Discard gasket.
4. Reverse procedure to install, then run engine and check for leaks.
