Removing and Installing Air Vent At Door

Removing And Installing Air Vent At Door

Removing air vent at door












1. With a screwdriver through the top air slot, release the retaining clips -A- and pull the air vent out of the dashboard.







2. Pull apart the electrical plug connection and remove the air vent.

Installing air vent at door







1. Push together the electrical plug connection.
2. Observe the line routing and insert the air vent into the dashboard until it clicks into place.
3. Raise the door seal and lay it over the air vent.
4. Check function of air vent illumination and air vent adjustment.
