Courtesy Lamp Bulb: Service and Repair

Removing and Installing Bulb For Luggage Compartment Light

Removal




1. Press out door warning light carefully using a screwdriver (arrow).
2. Remove defective bulb from between the contact springs.

Installation
1. Insert new bulb in the holes of the contact springs.
2. Install luggage compartment light in the trim panel and perform a function test.
