Oil Reservoir: Service and Repair

Removing And Installing Oil Tank Beginning With 1974 Models










Removal
1. Remove right rear wheel.
2. Drain oil.
3. Detach oil hoses and remove bolt from support tube of lower fender section.
4. Remove screws from support tube and turn it to the side.
5. Detach wires from oil level sender.
6. Detach breather hoses and remove tank cover from tank.
7. Unscrew oil filter.
8. Open the lock plate, remove nut, and pull out support tube through the bottom.
9. Remove oil tank retaining nuts and washers.

Installation
1. Glue wheelhouse gasket to oil tank in proper position.
