Seat Belt Height Adjuster: Service and Repair

Seat Belt Height Adjuster Replacement - Front

Removal Procedure




1. Remove the upper center pillar trim panel.
2. Remove the bolts (2) and the seat belt height adjuster (1).

Installation Procedure






Notice: Refer to Fastener Notice.

1. Install the seat belt height adjuster (1) with the bolts (2).

Tighten the seat belt height adjuster bolts to 27 N.m (20 lb ft).

2. Install the upper center pillar trim panel.
