Firefly (CANADA) L4-1.3L
>>
Repair and Diagnosis
>>
Powertrain Management
>>
Computers and Control Systems
>>
Engine Control Module
>>
Diagrams
>>
Connector Views
>>
C1
>>
Pins 1 - 20
Pins 1 - 20
Description:
