Home >> Pontiac >> 1991 >> Grand AM L4-151 2.5L >> Repair and Diagnosis >> A L L Diagnostic Trouble Codes ( DTC ) >> Testing and Inspection >> Manufacturer Code Charts >> - A Code Charts >> A018

A018

Fig. 16 Code A018 (Enable Relay Coil Circuit Shorted To Battery Positive, Or Coil Has Zero Ohms):
