Shift Linkage: Adjustments

Fig. 2 Wiring Diagram Of Mitsubishi Charging System:

1. Loosen adjustable swivel lock bolt, Fig. 2.
2. Place selector lever in P and move transmission control lever all the way to rear (in P detent).
3. With both levers still in P position, torque swivel clamp screw to 90 inch lbs.
