Installation Procedure

1. Install the rear seat center seat belt latch (1).

Notice: Refer to Fastener Notice in Cautions and Notices.

2. Install the rear seat center seat belt latch nut (2).

Tighten
Tighten the rear seat center seat belt latch nut to 42 N.m (31 lb ft).

3. Install the rear seat cushion.
