Installation Procedure

Description:

Installation Procedure

NOTICE: Refer to Fastener in Service Precautions.

1. Install two screws and the bracket assembly into center pillar near the roof.
Tighten
Tighten the screws to 25 N.m (19 lb. ft).
2. Install the anchor bolt for dual retractor into center pillar at rocker.
Tighten
Tighten the bolt to 40 N.m (30 lb. ft).
3. Install the anchor bolt for the guide loop into the bracket assembly.
Tighten
Tighten the bolt to 40 N.m (30 lb. ft).

IMPORTANT: When installing slide track, care must be taken to engage the head of the guide loop into the socket on the back of the slide track (five positions of adjustment are provided). After the trim is installed a check should be made to see if the slide track locks into all five positions.

4. Install the slide track and two screws.
5. Install the intermediate guide and screw.
6. Install the center pillar trim. Refer to Center Pillar Trim Replacement in Roof.
