Turn Signal Lamp Bulb Replacement - Rear

REMOVAL PROCEDURE

Turn Signal Lamp Bulb Replacement: Rear - Removal Procedure:

1. Open the rear compartment lid.
2. Remove the taillamp assembly from the rear body panel.
3. Rotate the turn signal lamp socket counterclockwise to release from the taillamp assembly.
4. Remove the bulb from the turn signal lamp socket.

INSTALLATION PROCEDURE

Turn Signal Lamp Bulb Replacement: Rear - Installation Procedure:

1. Install the bulb to the turn signal lamp socket.
2. Install the turn signal lamp socket to the taillamp assembly, then rotate the lamp socket clockwise to secure.
3. Install the taillamp assembly to the rear body panel.
4. Close the rear compartment lid.
