Assist Handle and Rear Coat Hook

REMOVAL PROCEDURE

Coat Hook Replacement: Removal Procedure:

1. Unsnap the plastic cover to expose coat hook (1) screw.
2. Remove the coat hook screw.
3. Remove the coat hook (1) from the headliner.

INSTALLATION PROCEDURE

Coat Hook Replacement: Installation Procedure:

1. Position the coat hook (1) to the headliner.
2. Install the coat hook screw.

Tighten
Tighten the coat hook screw to 2 Nm (18 lb in).

3. Snap the plastic cover over the coat hook (1) screw.
