Front Seal

REMOVAL PROCEDURE
Tools Required
J 38778 Door Trim Pad and Garnish Clip Remover

Seal Replacement: Hood Front - Removal Procedure:

1. Open the hood.
2. Remove the wiper arms.
3. Remove the windshield wiper washer hose from air inlet grille.
4. Remove the air inlet grille retainers using the J38778.
5. Remove the air inlet grille from the vehicle.

INSTALLATION PROCEDURE

Seal Replacement: Hood Front - Installation Procedure:

1. Install the air inlet grille to the vehicle.
2. Install the air inlet grille retainers.
3. Install the wiper arms.
