C1217

CIRCUIT DESCRIPTION
Ignition voltage is supplied through terminal A1 of the Electronic Brake Control Relay. The above condition enables the Electronic Brake Traction Control Module (EBTCM) to energize the pulling coil by completing the ground circuit at connector C1 terminal All of the EBTCM. The magnetic field created closes the Electronic Brake Control Relay contacts. The magnetic field also allows battery voltage and current through the Electronic Brake Control Relay terminal C1 to be supplied to the EBTCM through connector C2 terminal C and to the brake solenoid valves through S279.

CONDITIONS FOR SETTING THE DTC
DTC C1217 can set before the EBTCM commands the Electronic Brake Control Relay on.
DTC C1217 determines if the Electronic Brake Control Relay energizes when the Electronic Brake Control Relay should not energize. The above malfunction would not allow the Electronic Brake Control Relay to remove power to the ABS/ETS system.
If a second malfunction occurs, that requires the Electronic Brake Control Relay to turn off, the second malfunction cannot be removed if the Electronic Brake Control Relay cannot be controlled.

ACTION TAKEN WHEN THE DTC SETS
- A malfunction Diagnostic Trouble Code (DTC) stores.
- The ABS/ETS does not disable.

CONDITIONS FOR CLEARING THE DTC
- The condition responsible for setting the DTC no longer exists and the Scan Tool Clear DTCs function is used.
- 100 drive cycles pass with no DTCs detected.

DIAGNOSTIC AIDS
The following conditions may cause an intermittent malfunction:
- A poor connection
- Rubbed-through wire insulation
- A broken wire inside the insulation Use the enhanced diagnostic function of the Scan Tool in order to measure the frequency of the malfunction. Refer to the Scan Tool manual or Scan Tool Diagnosis for the procedure. Thoroughly inspect any circuitry that may be causing the intermittent complaint for the following conditions:
- Backed out terminals
- Improper mating
- Improperly formed or damaged terminals
- Poor terminal-to-wiring connections
- Physical damage to the wiring harness

Clear the DTCs after completing the diagnosis. Test drive the vehicle for three drive cycles in order to verify that the DTC does not reset. Use the following procedure in order to complete one drive cycle:
1. Start the vehicle.
2. Drive the vehicle over 16 km/h (10 mph).
3. Stop the vehicle.
4. Turn the ignition to the OFF position.
