Engine Mount: Service and Repair

TOOL REQUIRED
^ J 28467-A Engine Support Fixture

REMOVAL
1. Disconnect the negative battery cable.
2. Install the Engine Support Fixture.
3. Remove the ignition module. Set the module aside.
4. Remove the accessory drive belt.
5. Remove the supercharger drive belt tensioner.
6. Remove the power steering pump. Set the power steering pump aside. See Steering and Suspension.
7. Remove the torque axis engine mount.
8. Remove the nuts from the engine mount bracket.
9. Remove the studs from the engine mount bracket.





10. Remove the torque axis engine mount bracket.

INSTALLATION
1. Install the torque axis engine mount bracket.
2. Install the studs to the engine mount bracket.
3. Install the nuts to the engine mount bracket.
^ Tighten the upper nut to 30 Nm (22 ft. lbs.).
^ Tighten the lower nut to 70 Nm (52 ft. lbs.).
4. Install the torque axis engine mount.
5. Install the power steering pump. See Steering and Suspension.
6. Install the supercharger belt tensioner.
7. Install the ignition module.
8. Install the accessory drive belt.
9. Remove the Engine Support Fixture.
10. Connect the negative battery cable.
