Transaxle Brace

REMOVE OR DISCONNECT
1. Negative battery cable.
2. Raise vehicle and support the vehicle.
3. Right front tire and wheel assembly.
4. Right front splash shield.
5. Transaxle brace bolts.
6. Transaxle brace.

INSTALL OR CONNECT
1. Transaxle brace.
2. Transaxle brace to engine bolts.
3. Transaxle brace to transaxle bolts.
4. Right front splash shield.
5. Right front tire and wheel assembly, Refer to Steering And Suspension.
6. Lower vehicle.
7. Negative battery cable.
