Brake Pedal Assy: Service and Repair

Description:

Remove or Disconnect
1. Left sound insulator.
2. Rotate switch counterclockwise to remove from retainer in bracket
3. Wiring harness connectors.

Install or Connect
1. Wiring harness to switch.
2. Retainer into bracket (from forward side).
3. With brake pedal depressed, insert switch into retainer until switch seats on retainer.
4. Rotate switch clockwise to lock.

Adjust
A. Pull brake pedal fully rearward against pedal stop until audible clicks can not be heard.
B. Switch will be moved in retainer providing adjustment.
C. Release brake pedal and repeat Step A to assure that switch is properly adjusted.
5. Wiring harness connector(s).
6. Sound insulator
