Hydraulic Modulator Bracket

REMOVE OR DISCONNECT
1. Hydraulic modulator assembly.





2. Bracket mounting bolts.
3. Bracket.

INSTALL OR CONNECT
1. Bracket onto subframe.
2. Bracket mounting bolts. Tighten Bolts to 25 Nm (18 ft. lbs.).
3. Hydraulic modulator assembly.
