Outlet

REMOVAL
1. Drain the cooling system. See Cooling System.
2. Raise the vehicle. Support the vehicle suitably.
3. Disconnect the outlet hose from the oil cooler.
4. Disconnect the outlet hose from the thermostat bypass pipe.
5. Remove the outlet hose.

INSTALLATION
1. Install the outlet hose.
2. Connect the outlet hose to the thermostat bypass pipe.
3. Connect the outlet hose to the oil cooler.
4. Lower the vehicle.
5. Refill the coolant system. See Cooling System.
