Inlet

REMOVAL
1. Drain the cooling system. See Cooling System.
2. Raise the vehicle. Support the vehicle suitably.
3. Place the drain pan under the engine in order to catch any fluids that may drain.
4. Remove the oil filter.
5. Disconnect the inlet hose from the oil cooler.
6. Disconnect the inlet hose from the block fitting.
7. Remove the inlet hose.

INSTALLATION
1. Install the inlet hose.
2. Connect the inlet hose to the block fitting.
3. Connect the inlet hose to the oil cooler.
4. Install the oil filter. Lubricate the seal with engine oil. Hand tighten the filter to 13 Nm (115 inch lbs.).
5. Lower the vehicle.
6. Refill the coolant system. See Cooling System.
7. Add engine oil as necessary.
8. Inspect for leaks if necessary.
