Home >> Oldsmobile >> 1992 >> Cutlass Supreme FWD V6-189 3.1L >> Repair and Diagnosis >> Heating and Air Conditioning >> Testing and Inspection >> Component Tests and General Diagnostics >> Component Diagnostic Charts/Tests >> Air Delivery & Temperature Controls >> With RPO C68 >> Test D - Serial Data Line Test >> Table 2

Table 2

Test D: Serial Data Line Test (Table 2):
