Ignition Coil (With Built-In Ignition Power Transistor) Check

Ignition Coil (with Built-in Ignition Power Transistor) Check:

Check by the following procedure and replace if there is a malfunction.

SECONDARY COIL RESISTANCE CHECK
Measure the resistance between the high-voltage terminals of the ignition coil.

Standard value: 14 - 21 Ohms
