Special Tool - A/T Servo Compressor
84mitsubishi02SUBJECT:
SPECIAL TOOL-SERVO COMPRESSOR KM 171 AND KM 172 AUTOMATIC TRANSMISSIONS
NO. STB-84-21 -002
DATE March, 1984
MODEL Cordia, Tredia
The purpose of this bulletin is to update the 1983 and 1984 Cordia/Tredia Service Manuals to include procedures for the proper use of a newly introduced Special Tool, Servo Compressor #MD998341-01.
Please attach orange labels to pages 21-9, 21-76 and 21-89 of the 1983 Cordia/Tredia Service Manual, and pages 21-10, 21-74 and 21-88 of the 1984 Cordia/Tredia Service Manual as reference to this bulletin.
1983 CORDIA/TREDIA SERVICE MANUAL
PAGE 21-9 SPECIAL TOOLS
Delete references to Special Tools #MD998303 Compressor, Valve Spring and #MD998341 adapter set. The valve spring compressor is not used.
The new servo compressor #MD998341-01 is a threepiece tool which includes the adapter set.
PAGES 21-76 AND 21-89 COMPONENT SERVICE - AUTOMATIC TRANSAXLE ASSEMBLY
Change the Special Tool reference in Step 22 on page 21-76 and Step 41 on page 21-89 to Servo Compressor #MD998341-01. Refer to this photo rather than the one shown in the manual.
1984 CORDIA/TREDIA SERVICE MANUAL
PAGE 21-10 SPECIAL TOOLS
Add a reference to Servo Compressor #MD998341-01.
PAGE 21-74 COMPONENT SERVICE - AUTOMATIC TRANSAXLE ASSEMBLY
Step 25: The Special Tool shown in this step is not required. The force of the kickdown servo piston spring is enough to push the cover out after it is tapped with the butt of a hammer handle, or it may be pulled out using M5X0.8-25mm screws threaded into the holes in the cover.
PAGE 21-88 COMPONENT SERVICE - AUTOMATIC TRANSAXLE ASSEMBLY
Step 42 is now expanded to show the use of Servo Compressor #MD998341-01 to press the kickdown servo cover into place and hold it while the snap ring is being installed.
