Cruise Control Vacuum Vent Solenoid: Service and Repair

Brake Pedal Mounted

Fig. 69 Vacuum Dump Valve/Switch Removal:

1. Remove vacuum hose and disconnect electrical connector from switch.
2. Turn switch counterclockwise to release switch from mounting collar and remove switch, Fig. 69.
3. Reverse procedure to install.

Clutch Pedal Mounted

1. Hold switch and bracket assembly then disconnect vacuum hose and electrical connector from switch.
2. Push switch assembly out of spring collar.
3. Reverse procedure to install.
