A/C - Incorrect Information Label For Refrigerant Charge

Date: June 10, 2010

Order No: P-B-83.40/131

Group: 83

SUBJECT: MY-2010, Model 171.454 / 458 with Code 800

Information Label for Refrigerant Charge

Incorrect information labels for refrigerant charge were inadvertently applied at the plant.





All of the specified vehicles were filled correctly, however, the listed refrigerant quantity on the label is too high. All labels must be replaced on vehicles with Code 800 as of 12/2008 and all other vehicles up to 3/12/2010.





Label 2 (Figure 2) was applied at the plant, and should be replaced with label 1 (Figure 1).

The order number of the correct information labels can be determined via EPC-net using the VIN.
