GF54.30-P-3130SXJ Audio Menu Item, Function

GF54.30-P-3130SXJ Audio Menu Item, Function
- with CODE (498) Japan version

"Audio" menu item
If the "Audio" menu item in the main menu line is activated, the audio screen appears on the COMAND display (A40/8) and the audio application last executed is started. Should another audio application be started, then a change must be made to the main menu line again and the "Audio" menu item selected.

The following submenu items are available:
^ "FM"
^ "AM"
^ "CD"
Audio CD
^ "DVD-A"
Playback of audio DVDs
^ "MP3"
^ "Music servers"
^ "Aux"
^ "AVS"
The audio signals can be controlled from the rear of the vehicle
^ "Audio OFF"

The "Audio OFF" submenu item switches the audio sources off.

"Radio" submenu item
If the "Radio" submenu item has been activated, then the following functions can be selected in the submenu line:
^ "FM1"
Used to select "FM1" or "FM2"
^ "Memory"
List of the stored stations
^ "Tone"
Used to configure the audio output

The following contents are displayed in the main menu selection range:
^ the current station, the frequency and the number of the memory location
^ A pointer with which another station can be selected (by turning or pushing the turn/push control (A40/9s11) of the front central operating unit (A40/9) counterclockwise or clockwise)

"CD" submenu item
If the "CD" submenu item has been activated, then the following functions can be selected in the submenu line:
^ "CD"
Playback mode (normal track sequence, track shuffle)
^ "Track list"
List of tracks on the CD
^ "Changer"
List of the CDs/DVDs loaded in the changer
^ "Tone"
Sound settings

The following contents are displayed in the main menu selection range:
^ Name of the current track
^ Name of the CD
^ Number of current title
^ Elapsed time of the current track
^ Number of tracks on the CD
^ Playback mode

"DVD-A" submenu item
If the "DVD-A" submenu item has been activated, the following functions can be selected in the submenu line:
^ "DVD-A"
Playback mode (group, normal track sequence, repeat track, random track sequence)
^ "Pause"
Temporarily interrupts playback; the current position is stored and the menu item changes to "Play"
^ "Stop"
Stops playback
^ "Track list"
Track list
^ "Changer"
List of the CDs/DVDs loaded in the changer
^ "Tone"
Sound settings

The following contents are displayed in the main menu selection range:
^ Name of the current track
^ Name of the DVD
^ Number of current title
^ Elapsed time of the current track
^ Number of tracks on the DVD
^ Playback mode

"AVS" submenu item on model 221
Selecting the "AVS" submenu item allows audio signals to be output at the rear of the vehicle via the speaker system fitted in the vehicle.

"MP3" submenu item
If the "MP3" submenu item has been activated, then the following functions can be selected in the submenu line:
^ "MP3"
Playback mode
^ "Title A-Z"
List of tracks in alphabetical order
^ "Folder"
Tracks in the MP3 folder
^ "Changer"
List of the CDs/DVDs loaded in the changer
^ "Tone"
Sound settings

The following contents are displayed in the main menu selection range:
^ Name of the current track
^ Path of the current folder
^ Elapsed time of the current track
^ Number of tracks (depends on the playback mode)
^ Playback mode

MP3 files can be read by the following media:
^ CD
^ DVD
^ Storage medium via the PCMCIA drive

The following contents are displayed in the main menu selection range:
^ Name of the current track
^ Name of the CD
^ Number of current title
^ Elapsed time of the current track

"Music Server" submenu item
If the "Music Server" submenu item has been activated, the following functions can be selected in the submenu line:
^ "Music Register"
Play and recording function
^ "Edit"
Used for editing memory entries
^ "Play list"
List of the memory entries
^ "Changer"
List of the CDs/DVDs loaded in the changer
^ "Tone"
Sound settings

The following contents are displayed in the main menu selection range:
^ Name of the current track
^ Name of the CD
^ Number of current title
^ Elapsed time of the current track
