GF54.30-P-3130SXA Audio Menu Item, Function

GF54.30-P-3130SXA Audio Menu Item, Function
- with CODE (494) USA version
- except CODE (498) Japan version
- with CODE (527) COMAND APS with single DVD drive (with navigation)


"Audio" menu item
If the "Audio" menu item in the main menu line is activated, the audio screen appears on the COMAND display (A40/8) and the audio application last executed is started. Should another audio application be started, then a change must be made to the main menu line again and the "Audio" menu item selected.

The following submenu items are available:
^ "Radio"
^ "CD"
Audio CD
^ "DVD-A" with code (810) Sound system or with code (494) USA version
Playback of audio DVDs
^ "MP3" on vehicles with code (494) USA version, on CD/DVD or PCMCIA
^ "Rear"
The audio signals can be controlled from the rear of the vehicle
^ "Aux"
^ "Audio OFF"
The "Audio OFF" submenu item switches the audio sources off.

"Radio" submenu item
If the "Radio" submenu item has been activated, then the following functions can be selected in the submenu line:
^ "Radio"
Setting menu (station list, store station, enter frequency)
^ "Memory"
List of stored stations, automatic memory function used to automatically search for and store the 20 stations with the best reception
^ "FM"
Used to select various frequency bands
^ "AM", only on vehicles with code (494) USA version Used to select the AM frequency band
^ "Sound"
Used to configure the audio output

On vehicles with code (494) USA version, the frequency band "WB" (weather band) can also be selected in the submenu line.

The following contents are displayed in the main menu selection range:
^ the currently receivable stations and the numbers of their memory locations (the name of the station is displayed for stations with radio data system (RDS); the frequency is displayed for stations without RDS)
^ A pointer with which another station can be selected (by turning or pushing the turn/push control (A40/9s11) of the front central operating unit (A40/9) counterclockwise or clockwise)

"CD" submenu item
If the "CD" submenu item has been activated, then the following functions can be selected in the submenu line:
^ "CD"
Playback mode
^ "Track"
List of tracks on the CD
^ "Changer", with code (814) DVD changer or with code (494) USA version
List of the CDs/DVDs loaded in the changer
^ "Sound"
Sound settings

The following information is shown in the main menu:
^ Name of the current track
^ Name of the CD
^ Number of current title
^ Elapsed time of the current track
^ Number of tracks on the CD
^ Playback mode

"DVD-A" submenu item
If the "DVD-A" submenu item has been activated, the following functions can be selected in the submenu line:
^ "DVD-A"
Playback mode (group, normal track sequence, track shuffle)
^ "Pause"
Temporarily interrupts playback; the current position is stored and the menu item changes to "Play"
^ "Stop"
Stops playback
^ "Track"
Track list
^ "Changer", with code (814) DVD changer or with code (494) USA version
List of the CDs/DVDs loaded in the changer
^ "Sound"
Sound settings

The following contents are displayed in the main menu selection range:
^ Name of the current track
^ Name of the DVD
^ Number of current title
^ Elapsed time of the current track
^ Number of tracks on the DVD
^ Playback mode

"MP3" submenu item
If the "MP3" submenu item has been activated, then the following functions can be selected in the submenu line:
^ "MP3"
Playback mode
^ "Track A-Z"
List of tracks in alphabetical order
^ "Folder" Tracks in the MP3 folder
^ "Medium"
Used to select the medium
^ "Changer", with code (814) DVD changer or with code (494) USA version
List of the CDs/DVDs loaded in the changer
^ "Sound"
Sound settings

The following contents are displayed in the main menu selection range:
^ Name of the current track
^ Path of the current folder
^ Elapsed time of the current track
^ Number of tracks in the folder (depends on the selected playback mode)
^ Playback mode

MP3 files can be read by the following media:
^ CD
^ DVD
^ Storage medium via the PCMCIA drive

"Sat Radio" submenu item, with code (536) SIRIUS satellite radio
If the "Radio" submenu item has been activated, then the following functions can be selected in the submenu line:
^ "Sat Radio"
Satellite radio settings
^ "Presets"
Presets
^ "Info"
Information
^ "Category"
Station category
^ "Tone"
Sound settings
The stations of the category last selected appear after the system has been started. The memory location is also displayed in the case of stations that have already been stored.
