Rear

The blower regulator regulates the power supply for the rear blower depending on the speed set.







Blower switch position Blower control voltage
(reading on display) (manual)

1 segment 1.00V
2 segment 1.20V
3 segment 1.50V
4 segment 1.90V
5 segment 2.40V
6 segment 2.90V
7 segment 6.00V
