Without Memory

Model 210 as of July 1, 1999 except CODE (275a) Memory package (driver's seat, steering column, rearview mirrors)





Illustration
Driver-side semi-electric seat adjustment motor group (M25)

The driver-side semi-electric seat adjustment motor group (M25) consists of motors for raising and lowering the seat height (M25m1) and moving the seat backrest forward and back (M25m2). The passenger-side semi-electric seat adjustment motor group (M26) consists of the motors for raising and lowering the seat height (M26m1) and moving the seat backrest forward and back (M26m2).


Front seat adjustment motor group, function
The motors are permanently excited DC motors. They are equipped with thermal switches for protection against overheating.
