A/T - Improved 4-3 Downshift Under Partial Load
84mercedes02TO: OUR MERCEDES-BENZ PASSENGER CAR DEALERS
DATE: October, 1984 REF. NO. 27/70
SUBJECT: A. MODIFIED INTERMEDIATE PLATE AND GASKET TRANSMISSIONS 722.3 (GASOLINE ENGINES ONLY) AND 722.4 (GASOLINE AND DIESEL ENGINES)
B. ADDITIONAL RESTRICTOR ORIFICE INSTALLATION TRANSMISSION 722.4
A. Modified Intermediate Plate and Gasket Transmission 722.3 (Gasoline Engines Only) and 722.4 (Gasoline and Diesel Engines)
Modified intermediate plates and gaskets are now installed in the above transmissions to improve the partial-load 4-3 downshift.
Production Phase-In
Transmission As of Transmission
End Number
722.3 454 606
722.4 070 826
In case of complaints, modified parts can be installed in transmissions within the end number ranges below:
Model Transmission Transmission End
Number Range
107.045 722.3 112601-454605
126.033/043 722.3 110038-454605
126.032/037/044 722.3 below 454606
201.024/122 722.4 below 070826
FIGURE 1:
The gasket and intermediate plate have a modified hole pattern. Therefore, they can only be used in the following combinations.
Modified version:
Intermediate plate without holes (circled) and gasket with an additional hole (arrow, Figure 1).
NOTE: Vehicles with V-8 engine and transmissions with "B" position on shift console are already equipped with the modified intermediate plate. Therefore, only the modified gasket should be installed in case of a complaint (hard 4-3 downshift with partial load).
FIGURE 2:
Previous version (within the transmission end no. ranges on page 1):
Intermediate plate with holes (circled) and the gasket without an additional hole (Figure 2).
Parts Information
Part Name Part Number Transmission
Gasket 126 277 05 80 722.3
Intermediate Plate 126 277 76 14
Gasket 123 277 05 80 722.4
Intermediate Plate 123 277 35 14
Time Allowance
02-2725 01 Modified Intermediate Plate and Gasket, Install (Valve Body Removed) 0.4 hour
B. Additional Restrictor Orifice Installation, Transmission 722.4
In case of complaints about quick and hard reverse gear engagement, an additional orifice can be installed in the supply passage to the reverse gear piston.
This modification can be performed on vehicles with transmission end numbers below 070 826.
FIGURE 3:
Procedure (Valve body removed)
1. Remove lower cover (Service Microfiche, Automatic transmission 722.4, Job No. 430).
2. Insert additional restrictor orifice (arrow) in supply passage as shown (Figure 3).
3. Install valve body and lower cover.
Parts Information
Part Name Part Number Transmission
Restrictor Orifice 123 277 01 39 722.4
Time Allowance
02-2726 01 Additional Restrictor Orifice, Install (Valve Body Removed) 0.4 hour
