AR28.10-P-0100-02B Remove/Install Check Switch For Inter-Axle Differential Lock

AR28.10-P-0100-02B Remove/Install Check Switch For Inter-Axle Differential Lock
- MODEL 461, 463 with TRANSFER CASE 750.65









620 589 01 09 00
Wrench socket





1 Remove interaxle differential lock indicator switch (S76/7) at shift cylinder (1) with socket.
2 Install in the reverse order.

Note version when installing new interaxle differential lock indicator switch (S76/7).





Illustration of version 1





Illustration of version 2, retrofitted antilock brake system (ABS)

A 4 mm





Illustration of version 3, housing modification as of transmission 02607

B 11 mm
