Front Drain Hose Removal

FRONT DRAIN HOSE REMOVAL

1. Remove the following parts:
a. Front door Front Door Removal/Installation

b. Sail garnish Service and Repair

c. A-pillar trim A-Pillar Trim Removal/Installation

d. Front scuff plate inner Front Scuff Plate Removal/Installation

e. Rear scuff plate Rear Scuff Plate Removal/Installation

f. B-pillar lower trim B-Pillar Lower Trim Removal/Installation

g. Front seat belt upper anchor installation bolt Front Seat Belt Removal/Installation

h. B-pillar upper trim B-Pillar Upper Trim Removal/Installation

i. Rear package tray lid Service and Repair

j. Sub-trunk

k. Third-row seat Third-Row Seat Removal/Installation

l. Trunk end trim Trunk End Trim Removal/Installation

m. Rear header trim Rear Header Trim Removal/Installation

n. Third-row seat belt lower anchor installation bolt Third-Row Seat Belt Removal/Installation

o. Cargo compartment light Service and Repair

p. Trunk side trim

q. Second-row seat belt upper anchor installation bolt Second-Row Seat Belt Removal/Installation

r. C-pillar trim C-Pillar Trim Removal/Installation

s. Map light Service and Repair

t. Sunvisor Service and Repair

u. Assist handle Service and Repair

v. Headliner Headliner Removal/Installation

w. Front side trim Front Side Trim Removal/Installation

x. Side panel (passenger's side) Side Panel Removal/Installation

y. Side wall Side Wall Removal/Installation

z. Front console Front Console Removal/Installation

aa. Glove compartment Service and Repair

ab. Hood release lever Service and Repair

ac. Lower panel Lower Panel Removal/Installation

ad. Center panel unit Center Panel Removal/Installation

ae. Climate control unit Climate Control Unit Removal/Installation [Full-Auto Air Conditioner] Climate Control Unit Removal [Manual Air Conditioner] Climate Control Unit Installation [Manual Air Conditioner]

af. Car-navigation unit (vehicles with car-navigation system) Service and Repair

ag. Selector lever component Service and Repair

ah. Driver-side air bag module Driver-Side Air Bag Module Removal/Installation

ai. Meter hood Meter Hood Removal/Installation

aj. Lower column cover Service and Repair

ak. Instrument cluster Removal and Replacement

al. Steering shaft Service and Repair

am. Rear heat duct (1) Service and Repair

an. Windshield wiper arm and blade Windshield Wiper Arm And Blade Removal/Installation

ao. Cowl grille Cowl Grille Removal/Installation

ap. Dashboard Dashboard Removal/Installation

2. Disconnect the front drain hose from the sunroof frame.

3. Remove the front drain hose from the clips.






4. Pull the front drain hose into the vehicle interior and remove the front drain hose.
