Symptom Related Diagnostic Procedures

Refer to Fig. 10 through 12 when troubleshooting the starting system.

Fig. 10 Starting System Troubleshooting: Engine Will Not Crank, Starter Motor Does Not Operate:





Fig. 11 Starting System Troubleshooting: Engine Will Not Crank, Starter Motor Operates:





Fig. 12 Starting System Troubleshooting: Engine Will Not Crank, Starter Motor Does Not Operate:
