Transaxle Rear Support Insulator Removal/Installation

TRANSAXLE REAR SUPPORT INSULATOR REMOVAL/INSTALLATION









1. With the vehicle in NEUTRAL, position it on a hoist. See Lifting.

2. Remove the transaxle rear support insulator bolt.

- To install, tighten to 80 Nm {8.2 kgf-m, 59 ft-lbf}.

3. Remove the 2 rear transaxle support insulator nuts.

- To install, tighten to 80 Nm {8.2 kgf-m, 59 ft-lbf}.

4. Remove the transaxle rear support insulator through bolt and washer.

- To install, tighten to 115 Nm {11.7 kgf-m, 85 ft-lbf}.

5. Remove the transaxle rear support insulator.

6. If necessary, remove the 3 bolts and the transaxle rear support insulator bracket.

- To install, tighten to 48 Nm {4.9 kgf-m, 35 ft-lbf}.

7. To install, reverse the removal procedure.
