Valve-Guide Inner Diameter

VALVE-GUIDE INNER DIAMETER





1. Measure the inner diameter of the valve guides in two directions where indicated. Refer to SPECIFICATIONS.
2. If the valve guide is not within specifications, ream the valve guide and install a valve with an oversize stem or remove the valve guide and install a new valve guide.
